Curricular materials and resources to introduce your students to space plant biology and prepare them to participate in the Growing Beyond Earth classroom-based citizen science project
let currentCultivar = "Buena_Mulata_Pepper";
let growthProgress = 1; // continuous value, 1..18
let isPlaying = false;
let timerId = null;
// Seconds the trial has been actively running (playing). Resets to
// 0 on Reset, but otherwise only ever counts up while playing — the
// longer the trial runs, the higher the growth-rate bonus below.
let elapsedSeconds = 0;
// Base URL for the WordPress Media Library uploads folder holding
// the stage photos.
const IMAGE_BASE_URL = "https://fairchildgarden.org/wp-content/uploads/2026/08/";
// Maps each cultivar's internal name to the short filename prefix
// used in the uploaded image filenames (e.g. Robin_11.jpg).
const CULTIVAR_PREFIX = {
"Buena_Mulata_Pepper": "Buena",
"Heartbreaker_Dora_Red_Hybrid_Tomato": "Heart",
"Microtom_Tomato": "Micro",
"Red_Robin_Tomato": "Robin"
};
const TICK_MS = 250;
// How much each second of trial length adds to growthScore. No cap:
// this term keeps climbing for as long as the simulation plays.
const TRIAL_LENGTH_FACTOR = 0.05;
// Temperature bell curve driving growth rate: full strength
// (gaussian = 1) anywhere in the 22-25°C plateau, tapering off the
// further temp drifts outside that window.
const TEMP_PEAK_LOW = 22;
const TEMP_PEAK_HIGH = 25;
const TEMP_SIGMA = 2.5;
// Fruit set is shown visually through the image sequence rather
// than as a number. Buena Mulata, Microtom, and Red Robin are
// hard-capped at stage 12 — they never reveal the final 6 stages,
// regardless of temperature. Heartbreaker Dora Red Hybrid Tomato is
// also capped at 12 by default, but gradually unlocks into stages
// 13-18 the closer temperature sits to the 22-23°C plateau (see
// LAST6_PEAK_* below). The growth stage counter and progress bar
// still advance 1-18 as normal underneath.
const IMAGE_STAGE_CAP = {
"Buena_Mulata_Pepper": 12,
"Heartbreaker_Dora_Red_Hybrid_Tomato": 12,
"Microtom_Tomato": 12,
"Red_Robin_Tomato": 12
};
// Bell curve controlling how many of the last 6 images (13-18) are
// unlocked for Heartbreaker Dora Red: full 6 unlocked (gaussian = 1)
// anywhere in the 22-23°C plateau, fewer the further temp drifts
// outside that window.
const LAST6_PEAK_LOW = 22;
const LAST6_PEAK_HIGH = 23;
const LAST6_SIGMA = 1.5;
function last6UnlockGaussian(temp){
let distance = 0;
if (temp LAST6_PEAK_HIGH) distance = temp - LAST6_PEAK_HIGH;
return Math.exp(-(distance * distance) / (2 * LAST6_SIGMA * LAST6_SIGMA));
}
// Effective image-stage cap for a cultivar at a given temperature.
function getEffectiveCap(cultivar, temp){
const baseCap = IMAGE_STAGE_CAP[cultivar] || 18;
if (baseCap >= 18) return 18;
if (cultivar === "Heartbreaker_Dora_Red_Hybrid_Tomato") {
const unlockedExtra = Math.round(last6UnlockGaussian(temp) * 6);
return Math.min(18, baseCap + unlockedExtra);
}
// Buena Mulata, Microtom, Red Robin: hard cap, no unlock.
return baseCap;
}
function temperatureGaussian(temp){
let distance = 0;
if (temp TEMP_PEAK_HIGH) distance = temp - TEMP_PEAK_HIGH;
return Math.exp(-(distance * distance) / (2 * TEMP_SIGMA * TEMP_SIGMA));
}
function setCultivar(cultivar){
currentCultivar = cultivar;
document.querySelectorAll("#cultivarButtons button").forEach(btn => {
btn.classList.toggle("active", btn.dataset.cultivar === cultivar);
});
document.getElementById("cultivarLabel").textContent =
cultivar.replaceAll("_"," ");
resetGrowth();
}
const tempSlider = document.getElementById("tempSlider");
const humiditySlider = document.getElementById("humiditySlider");
const pressureSlider = document.getElementById("pressureSlider");
const co2Slider = document.getElementById("co2Slider");
function computeGrowthScore(){
const temp = Number(tempSlider.value);
const humidity = Number(humiditySlider.value);
const pressure = Number(pressureSlider.value);
const co2 = Number(co2Slider.value);
document.getElementById("tempLabel").textContent = temp + "°C";
document.getElementById("humidityLabel").textContent = humidity + "%";
document.getElementById("pressureLabel").textContent =
(pressure/1000).toFixed(1) + " kPa";
document.getElementById("co2Label").textContent = co2 + " ppm";
let growthScore = 0;
// Temperature: normal-distribution-shaped bonus peaking across
// the 22-25°C plateau (scaled so full peak contributes +6).
growthScore += temperatureGaussian(temp) * 6;
growthScore += (humidity - 40) * 1;
growthScore += 10 - Math.abs(pressure - 100000) / 500;
growthScore += (co2 - 400) * 0.01;
switch(currentCultivar){
case "Buena_Mulata_Pepper": break;
case "Heartbreaker_Dora_Red_Hybrid_Tomato": growthScore += 1.5; break;
case "Microtom_Tomato": growthScore += 3; break;
case "Red_Robin_Tomato": growthScore += 2.5; break;
}
// Trial length: the longer the trial has been running, the
// higher the growth rate — uncapped, so this keeps climbing.
growthScore += elapsedSeconds * TRIAL_LENGTH_FACTOR;
return growthScore;
}
// Converts the combined slider/cultivar/trial-length score into a
// rate, in growth-stages per second. Harsh conditions still creep
// forward (floor of 0.02) rather than freezing completely; ideal
// conditions move noticeably faster than poor ones.
function scoreToRate(growthScore){
const rate = 0.05 + growthScore * 0.03;
return Math.max(0.02, rate);
}
function refreshRateDisplay(){
const rate = scoreToRate(computeGrowthScore());
document.getElementById("rateLabel").textContent = rate.toFixed(2);
document.getElementById("trialLengthLabel").textContent = elapsedSeconds.toFixed(0) + "s";
}
function renderStage(){
const stage = Math.min(18, Math.max(1, Math.round(growthProgress)));
document.getElementById("stageLabel").textContent = stage;
const pct = ((growthProgress - 1) / 17) * 100;
document.getElementById("progressFill").style.width = pct + "%";
const cap = getEffectiveCap(currentCultivar, Number(tempSlider.value));
const imageStage = Math.min(stage, cap);
const prefix = CULTIVAR_PREFIX[currentCultivar];
// Try the PNG first — if the server has a real transparent PNG
// for this stage, it renders with its true colors and no
// blend-mode trick needed. If it 404s, handleImageError() falls
// back to the JPG with the fake-transparency blend.
const pngPath = IMAGE_BASE_URL + prefix + "_" + imageStage + ".png";
const jpgPath = IMAGE_BASE_URL + prefix + "_" + imageStage + ".jpg";
const img = document.getElementById("growthImage");
img.dataset.jpgFallback = jpgPath;
img.dataset.attemptedFallback = "false";
img.classList.remove("blend-fallback");
// Hide any stale placeholder while the new image attempts to load.
img.style.display = "block";
document.getElementById("imagePlaceholder").style.display = "none";
document.getElementById("missingPathLabel").textContent = pngPath;
img.src = pngPath;
}
function handleImageError(){
const img = document.getElementById("growthImage");
if (img.dataset.attemptedFallback !== "true" && img.dataset.jpgFallback){
// PNG not found at this stage — fall back to the JPG with
// the blend-mode fake-transparency trick.
img.dataset.attemptedFallback = "true";
img.classList.add("blend-fallback");
document.getElementById("missingPathLabel").textContent = img.dataset.jpgFallback;
img.src = img.dataset.jpgFallback;
return;
}
// Both PNG and JPG failed — genuinely missing.
img.style.display = "none";
document.getElementById("imagePlaceholder").style.display = "block";
}
function handleImageLoad(){
document.getElementById("growthImage").style.display = "block";
document.getElementById("imagePlaceholder").style.display = "none";
}
function tick(){
elapsedSeconds += TICK_MS / 1000;
const rate = scoreToRate(computeGrowthScore());
document.getElementById("rateLabel").textContent = rate.toFixed(2);
document.getElementById("trialLengthLabel").textContent = elapsedSeconds.toFixed(0) + "s";
growthProgress += rate * (TICK_MS / 1000);
if (growthProgress >= 18){
growthProgress = 18;
renderStage();
pausePlayback();
return;
}
renderStage();
}
function togglePlay(){
if (isPlaying){
pausePlayback();
} else {
startPlayback();
}
}
function startPlayback(){
if (growthProgress >= 18) return;
isPlaying = true;
document.getElementById("playBtn").textContent = "Pause";
timerId = setInterval(tick, TICK_MS);
}
function pausePlayback(){
isPlaying = false;
document.getElementById("playBtn").textContent = "Play";
if (timerId){
clearInterval(timerId);
timerId = null;
}
}
function resetGrowth(){
pausePlayback();
growthProgress = 1;
elapsedSeconds = 0;
refreshRateDisplay();
renderStage();
}
[tempSlider, humiditySlider, pressureSlider, co2Slider].forEach(s => {
s.addEventListener("input", refreshRateDisplay);
});
tempSlider.addEventListener("input", renderStage);
document.querySelector('[data-cultivar="Buena_Mulata_Pepper"]').classList.add("active");
refreshRateDisplay();
renderStage();
